JAC0212-C 12V – 2A Charger

The JAC0212-C (0891-46) 12v – 2 Amp Battery Charger is an automatic switch mode charger with float mode.

Description

12 Volt - 2 Amp
Automatic Switch Mode Charger with Float Mode

Model:
JAC0212-C

Dimensions (LxWxH):
119 x 61 x 37 mm

Weight:
0.5 kg

AC Input:
Input Voltage (Auto Sensing): 100 - 240 VAC, 50/60 Hz
Input Current Max: 1.6 Amps
Single Phase
Input Receptacle: IEC C8

DC Output:
Output Voltage - Nominal: 12 VDC
Output Voltage - Bulk / Cyclic Voltage: 14.6 VDC
Float Voltage: 13.5 VDC
Max DC Current: 1.6 Amps
Battery Type: Lead Acid
3 Stage Charging Profile: CC/CV/Float
Load Sensing, Minimum Voltage: 4 Volts

Features

Ambient Cooling
High Energy Efficiency (UEC, BC)
Voltage Limited
Current Limited
Over Voltage Protection
Over Temperature Protection
Final Float / Maintenance Mode
Plastic Case
Detachable AC Cord, 5 ft (NEMA 1-15/IEC C7)
Two-year Limited Warranty

Certifications

Safety – CE
DOE UEC Title 20, 10 CR, Part 430
California BC Energy Efficiency Compliant



Warning

This product can expose you to chemicals, including Lead and Lead Compounds, which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.p65warnings.ca.gov.
