JAC2512 12V – 25A Charger

The JAC2512 (0891-75) 12v – 25 Amp Battery Charger is an automatic switch mode charger with float mode.

Description

12 Volt - 25 Amp
Automatic Switch Mode Charger with Float Mode

Model:
JAC2512

Dimensions (LxWxH):
410 x 207 x 85 mm

Weight:
3.3 kg

AC Input:
Input Voltage Autosensing: 115/230 VAC, 50/60 Hz
Input Current Max: 15 Amps
Single Phase
Input Receptacle: IEC C14

DC Output:
Output Voltage - Nominal: 12 VDC
Output Voltage - Flooded: 14.8 VDC
Output Voltage - AGM / Gel: 14.4 VDC
Float Voltage: 13.4 VDC
Max DC Current: 25 Amps
Battery Type: Lead Acid: Standard, AGM, Gel
3 Stage Charging Profile: CC/CV/Float
Load Sensing, Minimum Voltage: 4 Volts

Features

Cooling Fan
Reverse Polarity Protection
High Energy Efficiency (UEC, BC)
Voltage Limited
Current Limited
Over Voltage Protection
Over Temperature Protection
Short Circuit Protection
Final Float / Maintenance Mode
Aluminum Case
Mounting Flanges
On / Off Switch
DC Output Cord 8 Ft. w/ Anderson SB50 Grey Connector
Detachable AC Cord, 5 ft (NEMA 5-15/IEC C13)
Two-year Limited Warranty

Certifications

Safety – CE
DOE UEC Title 20, 10 CR, Part 430
California BC Energy Efficiency Compliant



Warning

This product can expose you to chemicals, including Lead and Lead Compounds, which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.p65warnings.ca.gov.
